ForceBeyond produces heavy-duty, wear-resistant castings and forgings for the mining, excavation, construction, and material handling industries. Earthmoving equipment operates under continuous mechanical shock, heavy abrasion, and massive structural loads.
Utilizing automated sand casting, heavy-tonnage hot forging, and 5-axis CNC machining, we manufacture high-strength carbon steels, low-alloy chromoly steels (4140/4340), and ductile irons. Our components are heat-treated (Quenched & Tempered) to deliver extreme surface hardness while maintaining a ductile, fracture-resistant core.
| Material Grade | Hardness / Strength Profile | Target Mining & Excavation Application |
|---|---|---|
| AISI 4140 / 4340 Alloy Steel | Q&T Hardened up to 55+ HRC | High impact toughness and fatigue resistance for excavator drive shafts, pins, and linkages. |
| High-Manganese Steel | Work-hardens up to 500+ HBW | Crusher liners, hammer mill teeth, and jaw plates that harden under continuous impact. |
| Ductile Iron (A536 100-70-03) | Tensile Strength: 100,000 psi | Heavy-duty gearbox housings, planetary carriers, and track roller assemblies. |
| Ni-Hard / High-Chrome Iron | Abrasion Resistant (60+ HRC) | Slurry pump impellers, suction liners, and gravel pumping volutes exposed to abrasive slurry. |
ForceBeyond supplies high-strength, cost-effective cast and forged components for agricultural machinery OEMs. Farm machinery demands reliable performance in abrasive soil, high moisture, and heavy cyclic loads.
By combining low-cost automated green sand casting, precision investment casting, and closed-die forging, ForceBeyond delivers fully machined, powder-coated, and pre-assembled agricultural hardware directly to assembly lines.
| Manufacturing Process | Primary Materials | Key Components Produced |
|---|---|---|
| Automated Sand Casting | Ductile Iron (65-45-12), Gray Iron | Heavy tractor frame brackets, gearbox housings, axle trumpets, and counterweights. |
| Precision Hot Forging | AISI 1045, 4140 Alloy Steel | High-impact plow points, tiller tines, combine cutter bars, and hitch components. |
| Aluminum Die Casting | A380, A360 Aluminum Alloys | Lightweight belt covers, seed metering housings, and tractor cab hardware. |
| Kitting & Sub-Assembly | Multi-Material Integration | Pre-assembled planetary gear kits, hub assemblies, and sealed bearing modules. |
Agricultural OEMs face strict cost targets. ForceBeyond optimizes manufacturing economics through:
We utilize high-alloy martensitic steel compositions combined with precision Quench & Tempering (Q&T) or induction case-hardening to maximize surface wear resistance while maintaining core toughness.
Yes. Our high-capacity sand foundries can pour ductile iron and carbon steel castings weighing from a few pounds up to several tons.
We recommend Electro-deposition Coating (E-Coating) or heavy-duty thermosetting Powder Coating, which provide high salt spray resistance and chemical protection against corrosive fertilizers.
Yes. Our assembly cells press bearings, install seals, apply torque-verified fasteners, and package complete hub modules ready for immediate machine mounting.
Partner with our technical engineering team to manufacture high-wear, high-impact castings, forgings, and ready-to-install assemblies.
